VOLT

AIR & WATER

The HKD Volt is the "airless" low energy workhorse in our tower gun line up. The Volt incorporates our SV14 snowgun design and Rotary Valve Technology allowing 5 water flows.  The Volt is powered by a 7.5 HP (5 kW) compressor. The Volt is designed to cover your most critical, early opening terrain where hill air is not an option.

hkd-snow-makers-product-volt

thumb-volt-line-diagram

PRODUCT SPECS

Height: 10, 20, 30 ft / 3, 6, 9 m
Weight: 550, 580, 620 lbs / 250, 236, 281 kgs
Wet Bulb Start-Up: 28F / -2C
Water Flow: 14 - 80 gpm / 53 - 303 lpm
Minimum Water Pressure: 200 psi / 13 bar
Compressor: 7.5 HP (5.6 kW)
Power Requirement:11.7 amps at 480 volts / 7.5 amps at 600 volts
Throw: 30 - 125 ft / 9 - 38 m
Water Flow Stages:5 Stage
